Ubiquiti UniFi / Door Access
Panic Bar
Manufacturer part # UACC-PanicBar
A single-latched bar installed on emergency exit doors, allowing quick and easy egress by pushing the bar to open the door during emergencies.
Prepared for your project.
Pricing and availability are confirmed in your quote.
Unit of sale: each
Equipment and quantities reviewed Shipping confirmed before payment
Need help with this part? A closer look
Product details
Review the manufacturer’s information and tell us about any project-specific requirements.
Manufacturer / source details- Model
- UACC-PanicBar
- Catalog region
- United States
- Supply
- Availability and lead time confirmed with quote
- Dimensions
- 838 x 294 x 94 mm (33 x 11.6 x 3.7")
- Weight
- 5.8 kg (12.8 lb)
- Enclosure Material
- Aluminum, stainless steel
- Supported Door Width
- 3′ standard for door width of 2′4″ to 3′ (711 to 914 mm)
- Supported Door Thickness
- 1-3/4” (44 mm) and 2” (51 mm) thick of metal or wood door
- Strike
- For 3/4” (19 mm) stop
- Reversible
- Non-handed, reversible for all functions and trims
- Stiley
- 4-1/4” (108 mm) minimum
- Connection
- 2 lines for dry relay
- Wiring Connection
- Dry output Contact rating: 30V DC, 1A Push = Short/Release = Open
- Certifications
- UL 305, UL 10C, CAN/ULC-S132 ANSI/BHMA A156.3 Grade 1 Exit Devices Meets California Building Code Sec. 11B-309.4.
