Ubiquiti / Door Access
Enterprise Access Hub
SKU EAH-8
Enterprise-grade access hub with entry and exit control up to eight doors and battery backup support.
- (8) Lock terminals (12V or Dry)
- (8+8) Inputs for request-to-exit devices and door position sensors
- (8) PoE ports for Access Readers
each
We’ll confirm pricing, availability and shipping in your quote. Payment follows quote approval.
Need help with this part?Specifications
View manufacturer details- Model
- EAH-8
- Catalog region
- United States
- Supply
- Availability and lead time confirmed with quote
- Additional Inputs
- 16 Additional Inputs
- Lock Terminals
- 8 Lock Terminals
- AUX Terminals
- 4 AUX Terminals
- PoE
- 8 PoE Ports
- Dimensions
- 379 x 355 x 105 mm (15 x 14 x 4.1")
- Supported Doors
- 8
- Maximum User Count
- 10,000
- Input Terminals
- (8) Door exit request (8) Door position (1) Emergency
- Power Method
- Universal input, 100–240V AC, Max. 4.4A, 50/60 Hz 32–48V DC Lead Acid Battery, Max. 7.5A @32V
- UL 294 Level
- Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
- Weight
- Device: 9.1 kg (20 lb) Mount: 624 g (1.4 lb)
- Enclosure Material
- SGCC steel housing with polycarbonate cover
- Highlights
- (8) Lock terminals (12V or Dry); (8+8) Inputs for request-to-exit devices and door position sensors; (8) PoE ports for Access Readers; (4) AUX terminals for chimes, sirens, or door openers
