Camera Junction Box — White

Name: Camera Junction Box — White
Brand: Ubiquiti
SKU: UACC-Camera-JB-W

SKU UACC-Camera-JB-W

Tamper-resistant junction box for UniFi Bullet, Dome, and Turret cameras that enhances mounting durability, aesthetics, and ease of maintenance.

Select an option 2 available

Color

Exact part number

Quantity

each

We’ll confirm pricing, availability and shipping in your quote. Payment follows quote approval.

Specifications

Model: UACC-Camera-JB
Color: White
Catalog region: United States
Supply: Availability and lead time confirmed with quote
Dimensions: ⌀140.4 x 59.7 mm (⌀5.5 x 2.4")
Pole Mount Diameter: 1.5–2" (38–50 mm)
Weight: Junction box: 470 g (16.6 oz) Mount Holder: 66 g (2.3 oz) Deco ring: 17g (0.6 oz) Pole mount: 62 g (2.2 oz)
Enclosure Material: Aluminum alloy, polycarbonate
Mounting Material: Aluminum alloy
Threaded Outlets: G3/4"
Compatibility: UVC-AI-Bullet UVC-AI-PRO UVC-AI-DSLR UVC-AI-Dome UVC-AI-Turret UVC-G6-Bullet UVC-G6-Pro-Bullet UVC-G6-Edge-Bullet UVC-G6-Turret UVC-G6-Pro-Turret UVC-G6-Edge-Turret UVC-G6-Dome UVC-G6-Pro-Dome UVC-G6-Edge-Dome UVC-G6-Mini-Dome UVC-G6-180 UVC-G5-Dome UVC-G5-Dome-Ultra UVC-G5-Turret-Ultra UVC-G5-Pro UVC-G5-Bullet UVC-G4-Pro UVC-G4-Bullet UVC-G4-Dome UVC-G3-Pro UVC-G3-Bullet
Highlights: Supports flat surface, pole and pendant mounting; Includes side and rear 3/4" conduit entrances
