Switch Enterprise Campus 48S PoE

SKU ECS-48S-PoE

Enterprise-grade 48-port, Layer 3 Etherlighting™ PoE+++ switch with Stacking support and high-capacity 10 GbE RJ45 and 25G SFP28 connections for high availability system design.

200-240V AC Shared Mode: 2,150W 100-120V AC Shared Mode: 1,750W 200-240V AC Redundant Mode: 950W 100-120V AC Redundant Mode: 750W

Quantity

We’ll confirm pricing, availability and shipping in your quote. Payment follows quote approval.

Specifications

View manufacturer details

Model: ECS-48S-PoE (2150W)
Catalog region: United States
Supply: Availability and lead time confirmed with quote
Dimensions: 442.4 x 44 x 496 mm (17.4 x 1.7 x 19.5")
1 GbE RJ45: 1 (1G/100M/10M)
2.5 GbE RJ45: 32 (All PoE+++) (2.5G/1G/100M/10M)
10 GbE RJ45: 16 (All PoE+++) (10G/5G/2.5G/1G/100M/10M)
25G SFP28: 4 (25G/10G/1G)
100G QSFP28: 2 (100G)
Console: 1
Max. PoE Output: Up to PoE+++
Total PoE Availability: 200-240V AC Shared Mode: 2,150W 100-120V AC Shared Mode: 1,750W 200-240V AC Redundant Mode: 950W 100-120V AC Redundant Mode: 750W
Redundancy: Switch Stacking (2) Hot-Swappable PSUs (4) Hot-Swappable Fans
Form Factor: Rack Mount (1U, Full-Depth)
Switching Capacity: 680 Gbps

Switch Enterprise Campus 48S PoE
